Oil Line Angle Connector 3/8" Female × 1/4" Male × 1200mm is an industrial spare component used for Oil Burner Fuel Pump Suction Lines. STARNEX Industrial Spares supplies this replacement component in Kenya with technical sourcing support across East Africa. Before ordering, confirm the required dimensions, connection standards, and equipment model with our technical sales team.
Oil Line Angle Connector 3/8" Female × 1/4" Male × 1200mm
Oil Line Angle Connector 3/8" Female × 1/4" Male × 1200mm is an industrial spare component used for Oil Burner Fuel Pump Suction Lines. STARNEX Industrial Spares supplies this replacement component in Kenya with technical sourcing support across East Africa. Before ordering, confirm the required dimensions, connection standards, and equipment model with our technical sales team.
Functional engineering application
The Oil Line Angle Connector 3/8" Female × 1/4" Male × 1200mm (MPN: OL-ANG-38F-14M-1200) is built for continuous-duty industrial piping, holding pressure, temperature, and cycling loads in factory installations across Kenya and East Africa.
Quotation & fulfilment
Parametric technical attributes
| Generic OL-ANG-38F-14M-1200 | |
| IDENTIFICATION | |
| Component Type | Oil Line Angle Connector 3/8" Female × 1/4" Male × 1200mm |
| Manufacturer / Brand | Generic |
| Part Number (MPN) | OL-ANG-38F-14M-1200 |
| Stock Keeping Unit (SKU) | GEN-OL-38F14M1200 |
| TECHNICAL PARAMETERS | |
| Product Name | Angle Oil Line Hose 1200mm |
| Hose Length | 1200 mm (1.2 Meters) |
| Fitting 1 | 3/8" BSP Female Swivel (90° Angle Elbow) |
| Fitting 2 | 1/4" BSP Male Threaded Straight |
| Fluid Compatibility | Light Oil / Heavy Oil / Diesel / Kerosene |
| Weight | 0.42 kg |
| PERFORMANCE & RATINGS | |
| Maximum Working Pressure | 10.0 bar |
| Burst Pressure | 30.0 bar |
| Operating Temperature | -20 °C to +100 °C |
| CONSTRUCTION & CONNECTION | |
| Core Tube Material | NBR Oil-Resistant Synthetic Rubber |
| Outer Braid Material | AISI 304 Stainless Steel Wire |
| Fitting Material | Nickel-Plated Carbon Steel |
| Inner Diameter (DN) | DN 8 (8.0 mm) |
| COMPLIANCE & LOGISTICS | |
| Stock Availability | In Stock — Enterprise Rd, Nairobi |
| KRA Tax Status | Official KRA E-TIMS Tax Invoice Available |
System fitment & verified replacements
Verified interchangeable models
Commonly installed on equipment from
Common questions on this part
The 90° angle fitting prevents tight kinking of the hose when connecting to fuel pump ports located close to burner body casings or mounting brackets.
This hose is rated for a continuous working pressure of 10.0 bar (145 psi) with a safety burst rating of 30.0 bar.
Yes, the NBR inner tube and stainless braiding are compatible with HFO up to 100°C operating temperature.
The swivel nut utilizes a precision 60° cone seat for metal-to-metal sealing, requiring no copper washer on matching male cone fittings.
It is recommended to inspect flexible oil hoses annually and replace them every 3 to 5 years per EN industrial safety guidelines.
Yes, 1200mm (1.2 meters) provides ample slack so boiler maintenance technicians can swing open hinged burner doors without disconnecting fuel lines.
Yes, the heavy inner core resists collapse under vacuum pressures up to -0.8 bar.
Yes, STARNEX stocks straight 3/8" x 1/4" and 3/8" x 3/8" braided fuel hoses in 1000mm and 1200mm lengths.
Use standard open-end spanners (19mm and 17mm) to hold the fitting body while tightening the swivel nut to prevent twisting the hose braid.
Yes, all orders from STARNEX include official KRA E-TIMS tax documentation.
